Колпаки - TC

Дюймовая труба

D нар.

трубы T

(мм)

Основной серийный номер

Габариты, дюймы (мм)

L

C

D

F

1/16

ER-TC-FT1

0.59(15.0)

0.34(8.6)

0.31(7.9)

0.31(7.9)

1/8

ER-TC-FT2

0.79(20.1)

0.50(12.7)

0.44(11.1)

0.44(11.1)

3/16

ER-TC-FT3

0.84(21.3)

0.54(13.7)

0.50(12.7)

0.44(11.1)

1/4

ER-TC-FT4

0.92(23.4)

0.60(15.2)

0.56(14.3)

0.50(12.7)

5/16

ER-TC-FT5

0.96(24.4)

0.64(16.3)

0.63(15.9)

0.56(14.3)

3/8

ER-TC-FT6

1.01(25.7)

0.66(16.8)

0.69(17.5)

0.63(15.9)

1/2

ER-TC-FT8

1.15(29.2)

0.90(22.9)

0.87(22.2)

0.81(20.6)

5/8

ER-TC-FT10

1.18(30.0)

0.96(24.4)

1.00(25.4)

0.94(23.8)

3/4

ER-TC-FT12

1.24(31.5)

0.96(24.4)

1.13(28.6)

1.06(27.0)

7/8

ER-TC-FT14

1.34(34.0)

1.02(25.9)

1.25(31.8)

1.19(30.2)

1

ER-TC-FT16

1.51(38.4)

1.23(31.2)

1.50(38.1)

1.37(34.9)

1 1/8

ER-TC-FT18

1.51(38.4)

1.23(31.2)

1.81(46.0)

1.63(41.3)

1 1/4

ER-TC-FT20

2.10(53.3)

1.62(41.1)

1.87(47.6)

1.75(44.5)

1 1/2

ER-TC-FT24

2.54(64.5)

1.97(50.0)

2.25(57.2)

2.13(54.0)

2

ER-TC-FT32

3.41(86.6)

2.66(67.6)

3.00(76.2)

2.75(70.0)

Метрическая труба

D нар.

трубы T

(мм)

Основной серийный номер

Габариты, мм (дюймы)

L

C

D

F

2

ER-TC-MT2

20.1(0.79)

12.9(0.51)

12.0(0.47)

12.0(0.47)

3

ER-TC-MT3

20.1(0.79)

12.9(0.51)

12.0(0.47)

12.0(0.47)

4

ER-TC-MT4

21.3(0.84)

13.7(0.54)

12.0(0.47)

12.0(0.47)

6

ER-TC-MT6

23.1(0.91)

15.3(0.60)

14.0(0.55)

14.0(0.55)

8

ER-TC-MT8

24.5(0.96)

16.2(0.64)

16.0(0.63)

15.0(0.59)

10

ER-TC-MT10

26.6(1.05)

17.2(0.68)

19.0(0.75)

18.0(0.71)

12

ER-TC-MT12

29.1(1.15)

22.8(0.90)

22.0(0.87)

22.0(0.87)

14

ER-TC-MT14

29.9(1.18)

24.4(0.96)

22.0(0.87)

24.0(0.94)

15

ER-TC-MT15

29.9(1.18)

24.4(0.96)

25.0(0.98)

24.0(0.94)

16

ER-TC-MT16

29.9(1.18)

24.4(0.96)

25.0(0.98)

24.0(0.94)

18

ER-TC-MT18

31.4(1.24)

24.4(0.96)

30.0(1.18)

27.0(1.06)

20

ER-TC-MT20

34.0(1.34)

26.0(1.02)

32.0(1.26)

30.0(1.18)

22

ER-TC-MT22

34.0(1.34)

26.0(1.02)

32.0(1.26)

30.0(1.18)

25

ER-TC-MT25

38.5(1.52)

31.3(1.23)

38.0(1.50)

35.0(1.38)

28

ER-TC-MT28

48.5(1.91)

36.6(1.44)

46.0(1.81)

41.0(1.61)

30

ER-TC-MT30

53.4(2.10)

39.6(1.56)

50.0(1.97)

46.0(1.81)

32

ER-TC-MT32

55.8(2.20)

42.0(1.65)

50.0(1.97)

46.0(1.81)

38

ER-TC-MT38

65.4(2.57)

49.4(1.94)

60.0(2.36)

55.0(2.17)

50

ER-TC-MT50

86.0(3.38)

67.6(2.66)

75.0(2.95)

70.0(2.75)
